Are the Speakers in the Dodge Caravan Rear 6 9? The Definitive Guide
Yes, the primary rear side panel speakers in the Dodge Grand Caravan (specifically the 2008–2020 models) are 6×9 inches. While most trim levels use this standard size, some premium audio packages include additional smaller speakers in the D-pillars, but the main rear output comes from the 6×9-inch drivers located in the rear quarter panels.
Upgrading the audio in a Dodge Caravan is one of the most rewarding DIY projects you can tackle. I have spent years tearing down interior panels on Mopar vans, and I can tell you that while the factory paper-cone speakers are underwhelming, the 6×9 cavity offers incredible potential for deep bass and clear mid-range without needing a dedicated subwoofer.
Key Takeaways: Dodge Caravan Speaker Basics
- Rear Side Panels: Almost exclusively 6×9 inches across all 5th Gen (2008–2020) models.
- Front Doors: Also utilize 6×9-inch speakers, making a full set of four 6x9s a common upgrade path.
- Dash Speakers: Typically 3-1/2 inches, used for high-frequency “fill” in premium systems.
- Depth Clearance: Most standard 6×9 speakers fit, but extremely deep magnets may require a small spacer.
- Difficulty: Front doors are a 3/10; Rear side panels are a 6/10 due to the extensive trim removal required.
Complete Speaker Size Chart: Dodge Grand Caravan (2008–2020)
Before you purchase new hardware, it is vital to know exactly what is inside your specific trim level. In my experience, the Stow ‘n Go seating significantly impacts how you access these locations.
| Speaker Location | Factory Size | Recommended Upgrade | Complexity |
|---|---|---|---|
| Front Dash (L/R/C) | 3-1/2″ | High-quality Silk Dome Tweeters | Easy |
| Front Doors | 6×9″ | 2-Way or 3-Way 6x9s | Moderate |
| Rear Side Panels | 6×9″ | High-Sensitivity 6x9s | Hard |
| Rear D-Pillars | 2-1/2″ | Ignore or Replace with 1″ Tweeters | Moderate |
Why the “Are the Speakers in the Dodge Caravan Rear 6 9” Question Matters
When I first started working on the Dodge Grand Caravan platform, I noticed a lot of confusion regarding the rear speakers. Because the van is so large, many owners assume there are 6.5-inch round speakers hidden in the back.
However, Dodge opted for 6x9s because they provide more surface area than a 6.5-inch speaker. This extra surface area is crucial for moving air in a large cabin, providing the “thump” that families want during long road trips. If you are looking for more bass without installing a bulky sub-box that ruins your Stow ‘n Go functionality, a high-quality set of 6×9-inch speakers is your best bet.
Step-by-Step Guide: Replacing Rear 6×9 Speakers
Replacing the rear speakers is the most labor-intensive part of a Caravan audio overhaul. Unlike the front doors, where you just pop a panel, the rear requires moving seats and pulling large plastic trim pieces.
Tools You Will Need
- Panel Removal Tool Set (Plastic is preferred to avoid scratching the interior).
- 10mm Socket and Ratchet.
- Phillips Head Screwdriver.
- T20 Torx Driver (Depending on the year model).
- Wire Strippers or Crutchfield Wiring Harnesses.
Step 1: Clear the Workspace
Fold your Stow ‘n Go seats into the floor. You need a flat surface to move around on. I’ve tried doing this with the seats up, and it is a recipe for a sore back and broken plastic clips.
Step 2: Remove the Threshold and Pillar Trim
Start at the rear hatch. Remove the plastic scuff plate at the bottom of the trunk opening by pulling straight up. Then, work your way forward, loosening the lower trim panels along the floor.
Step 3: Unscrew the Side Panels
There are usually 10mm bolts or Phillips screws hidden behind small plastic “trap doors” or inside the cup holders. Pro Tip: Keep a magnetic tray nearby. Losing a screw inside the metal body of a Dodge Caravan is a nightmare I don’t wish on anyone.
Step 4: Accessing the Speaker
Once the panel is loose, pull it out just enough to see the 6×9 speaker. You do not necessarily have to remove the entire panel from the van, which saves you from disconnecting the seatbelt anchors. Reach in with a short “stubby” screwdriver to remove the four screws holding the 6×9 in place.
Step 5: Wiring and Installation
The factory plug is proprietary. I always recommend using a Metra 72-6514 Speaker Harness. This allows you to plug your new speakers directly into the factory wiring without cutting or soldering. If you do cut the wires, ensure your polarity is correct; otherwise, your bass will “cancel out,” leaving the system sounding thin and tinny.
Expert Insights: Choosing the Best 6x9s for Your Caravan
Not all 6×9 speakers are created equal. Because the Dodge Caravan often uses a low-powered factory head unit (even the Uconnect systems), you need to look at Sensitivity ratings.
Sensitivity is Key
Look for speakers with a Sensitivity rating of 90dB or higher. Brands like Hertz, Blam, and the Rockford Fosgate Punch Series excel here. High sensitivity means the speaker can produce more volume with less power—perfect for the modest internal amp of a stock Dodge radio.
Way vs. 3-Way
- 2-Way Speakers: Features a woofer and a tweeter. I prefer these for the rear as they provide cleaner mid-bass.
- 3-Way Speakers: Adds a “super-tweeter.” These can sometimes sound a bit “bright” or “harsh” in the metal-and-plastic environment of a van, but they offer great clarity for passengers in the very back.
Common Issues with Dodge Caravan Audio Systems
In my time troubleshooting these vans, I’ve encountered three recurring problems that you should check while you have the panels off:
- Blown Voice Coils: The factory Infinity or Alpine speakers often have foam surrounds that rot over 5–10 years. If your audio sounds like “crackling,” the speaker is physically falling apart.
- Wiring Shorts in the Door Jam: If your front speakers cut in and out, check the rubber boot between the door and the frame. The constant sliding/opening of doors can fatigue the copper wire.
- Head Unit Freezes: The MyGig or Uconnect 430/730N units are known for hard drive failures. If your speakers are fine but the screen is black, the issue is the “brain,” not the “voice.”
Boosting Performance: Sound Deadening
Since you are already asking “are the speakers in the dodge caravan rear 6 9,” you likely care about sound quality. The rear quarter panels of a van are essentially giant hollow metal drums.
I highly recommend applying a few sheets of Butyl Sound Deadener (like Dynamat or Noico) to the outer metal skin behind the speaker. This simple step:
- Reduces road noise.
- Eliminates plastic panel rattles.
- Tightens the “punch” of your new 6×9-inch speakers.
Frequently Asked Questions
Can I put 6.5-inch speakers in the rear of a Dodge Caravan?
Yes, but you will need a 6×9 to 6.5-inch adapter bracket. While 6.5-inch speakers offer more “audiophile” options, you will lose some of the low-end bass response that a 6×9 naturally provides.
Are the speakers in the Dodge Caravan rear 6 9 across all years?
The 6×9 size has been standard for the rear side panels since the 4th generation (2001). However, the mounting depth and the way you access the panels changed significantly starting in 2008 with the introduction of the 5th generation.
Does the premium Alpine system use different sized speakers?
No, the sizes remain the same (6×9 in the doors and rear panels). The difference is the impedance (ohms) and the addition of an external amplifier located behind the rear driver-side trim panel. If you have the Alpine system, ensure your new speakers are compatible with the factory amp’s ohm rating (usually 2-ohm or 4-ohm).
How long does it take to replace the rear speakers?
For a beginner, expect the rear speaker replacement to take 2 to 3 hours. The front doors can be done in about 45 minutes. The bulk of your time will be spent carefully prying plastic clips without breaking them.
